Kamera | ||
---|---|---|
Görüntü Sensörü: | | | 1/3” SONY CCD |
İşaret Sistem: | | | PAL/NTSC |
Etkin Piksel: | | | PAL: 976 (H) × 582 (V) NTSC: 976 (H) × 494 (V) |
Minimum Aydınlatma: | | | 0.001Lux @ (F1.2,AGC ON) |
Objektif Zamanı: | | | 1/50(1/60)s to 1/100,000s |
Lens: | | | 2.8 – 12 mm @ F1.4 Angle of view: 80° – 27.2° |
Lens Montaj : | | | φ14 |
Otomatik Iris: | | | DC Drive |
Ayarlama Aralık: | | | Pan: 0 – 355°, Tilt: 0 – 75°, Rotation: 0 – 355° |
Gündüz ve Gece: | | | Electronic |
Senkronizasyon: | | | Internal Synchronization |
Video Çıkışı: | | | 1Vp-p Composite Output (75Ω/BNC); Test Monitor OUT [1Vp-p Composite Output (75Ω/BNC),Device Line] |
S / N Oranı: | | | More than 62 dB |
Menü | ||
Kamera ID: | | | On / Off (52 letters, position adjustable) |
Otomatik Kazanç: | | | Low/Middle/High/Off |
D / N Modu: | | | Auto/Day/Night |
Otomatik Beyaz Dengesi: | | | ATW/Push/User1/User2/Anti CR/Manual/Push lock |
Gizlilik Maskesi: | | | On/Off, maximum 8 zones |
Hareket Algılama: | | | ON/Off |
BLC: | | | BLC/HLC/Off |
Tutulma: | | | On / off |
Ölü Pixel Algılama: | | | Yes |
Fonksiyon: | | | ATR, HLC, DNR, Sharpness, Brightness, Contrast, Hue, Gain, Mirror, Defect Pixel Correction |
Genel | ||
Çalışma Sıcaklığı: | | | -10 °C – 60 °C (14 °F – 140 °F) Humidity 90% or less (non-condensing) |
Güç Kaynağı: | | | 12 V DC±10% |
Güç Tüketim: | | | Max. 2 W |
Darbe Koruma: | | | IEC60068-2-75 test, Eh, 50J; EN50102, up to IK10. |
Weather Proof: | | | IP66 |
Boyutlar: | | | Φ 139.9 × 99.9 mm (Φ 5.51” × 3. 93”) |
Ağırlık: | | | 800 g (1.76 lbs) |
Kurulum Dosyaları |
---|
