Kamera | ||
---|---|---|
Görüntü Sensörü: | | | 2MP CMOS Image Sensor |
İşaret Sistem: | | | PAL/NTSC |
Etkin Piksel: | | | 1920(H)*1080(V) |
Minimum Aydınlatma: | | | 0.003 Lux@(F1.2, AGC ON), 0 Lux with IR |
Objektif Zamanı: | | | 1/25(1/30) s to 1/15,000 s |
Lens: | | | 2.8 mm to 12 mm |
Lens Montaj : | | | φ14 |
Ayarlama Aralık: | | | Pan: 0° to 340°, Tilt: 0° to 75°, Rotate: 0° to 355° |
Gündüz ve Gece: | | | IR cut filter with auto switch |
Geniş Dinamik Aralık: | | | 75dB |
Video Çerçeve Hızı: | | | PAL: 1080p@25fps NTSC: 1080p@30fps |
HD Video Çıkışı: | | | 1 Analog HD output |
Senkronizasyon: | | | Internal Synchronization |
CVBS Çıkışı: | | | 1Vp-p Composite Output(75Ω/BNC) |
Coax üzerinden: | | | Support |
Menü | ||
D / N Modu: | | | Auto / Color / B/W |
AGC: | | | Support |
Fonksiyon: | | | Defog, Mirror, Defective Pixel Correction, Sharpness, Camera Title |
Alan: | | | Indoor/outdoor/indoor1/low light |
Genel | ||
Çalışma Sıcaklığı: | | | -40 °C – 60 °C (-40 °F – 140 °F) Humidity 90% or less (non-condensing) |
Güç Tüketim: | | | Max: 6 W |
IR Aralık: | | | Up to 40m |
Communication : | | | Up the coax Protocol: HIKVISION-C(Coaxitron) |
Boyutlar: | | | Φ 136 mm × 101.9 mm (5.35″ × 4.01″) |
Ağırlık: | | | Approx. 800 g (1.76 lb.) |
