Kamera | ||
---|---|---|
Görüntü Sensörü: | | | 1/3″ Progressive Scan CMOS |
Minimum Aydınlatma: | | | 0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR 0.19 Lux @ (F2.0, AGC ON) ,0 Lux with IR |
Objektif Hızı: | | | 1/3 s to 1/100,000 s |
Lens: | | | 4mm@ F2.0 (2.8mm, 6mm optional), Angle of view: 98.5°(2.8mm), 79°(4mm) , 49°(6mm) |
Lens Kurulumu: | | | M12 |
Ayarlanan Aralık: | | | Pan:0° – 355°, Tilt: 0° – 75°, Rotation: 0-355° |
Gündüz & Gece: | | | IR cut filter with auto switch |
Geniş Dinamik Aralık: | | | Digital WDR |
Dijtal Gürültü Azaltma: | | | 3D DNR |
Sıkıştırma Standardı | ||
Video Sıkıştırma: | | | H.264/MJPEG |
H.264 Türü: | | | Main Profile |
Video Bit Hızı: | | | 32Kbps~12Mbps |
Ses Sıkıştırma: | | | -S: G.711/G.722.1/G.726/MP2L2 |
Ses Bit Hızı: | | | 64Kbps(G.711) /16Kbps(G.722.1)/16Kbps(G.726) /32-128Kbps(MP2L2) |
Çift Akış: | | | Yes |
Görüntü | ||
Maksimum Çözünürlük: | | | 2048×1536 |
Çerçeve Hızı: | | | 50Hz: 20fps(2048 × 1536), 25fps(1920 × 1080), 25fps (1280 × 720) 60Hz: 20fps(2048 × 1536), 30fps(1920 × 1080), 30fps (1280 × 720) |
Görüntü Ayarlama: | | | Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
BLC: | | | Yes, zone configurable |
ROI: | | | Support |
Ağ | ||
Ağ Depolama: | | | Built-in Micro SD/SDHC/SDXC slot, up to 128G, NAS(NFS, SMB/CIFS) |
Alarm Trigger: | | | Line Crossing, Intrusion Detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
Protokoller: | | | TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
Güvenlik: | | | One-key reset, Anti-Flicker, heartbeat, mirror, password protection, privacy mask, Watermark, IP address filtering, Anonymous access |
Sistem Uyumluluğu: | | | ONVIF, PSIA, CGI, ISAPI |
Arayüzü | ||
Ses: | | | 1-ch 3.5 mm audio in (Mic in/Line in)/out interface (-S model) |
İletişim Arayüzü: | | | 1 RJ45 10M / 100M Ethernet interface |
Alarm: | | | -S: 1 alarm I/O |
Wi-Fi Şartnamesi (-W) | ||
Kablosuz Standartlar: | | | IEEE802.11b, 802.11g, 802.11n |
Frekans Aralığı: | | | 2.4 GHz ~ 2.4835 GHz |
Kanal Bant Genişliği: | | | 20/40MHz Support |
Modülasyon Modu: | | | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
Güvenlik: | | | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS |
Güç İletim: | | | 11b: 17±1.5dBm @ 11Mbps 11g: 14±1.5dBm @ 54Mbps 11n: 12.5±1.5dBm |
Alıcı Hassasiyeti: | | | 11b: -90dBm @ 11Mbps (Typical) 11g: -75dBm @ 54Mpbs (Typical) 11n: -74dBm (Typical) |
İletim Hızı: | | | 11b: 11Mbps 11g: 54Mbps 11n: up to 150Mbps |
Kablosuz Menzil: | | | 50m(depend on environment) |
Protokoller: | | | 802.11b: CCK, QPSK, BPSK 802.11g/n: OFDM |
Genel | ||
Çalışma Sıcaklığı: | | | -30 °C ~ 60 °C (-22 °F ~ 140 °F) Humidity 95% or less (non-condensing) |
Güç Kaynağı: | | | 12 VDC ± 10%, PoE (802.3af) |
GÜç Tüketimi: | | | Max. 5 W |
Darbe Koruma: | | | IEC60068-2-75Eh, 50J; EN50102, IK10 |
Weather Proof: | | | IP66 |
IR Aralık: | | | Up to 30m |
Boyutlar: | | | Φ111 × 82 (4.4” × 3.2”) |
Ağırlık: | | | 500g (1.1 lbs) |
NOT: | | | “-W” series support Wi-Fi (802.11b/g/n) and the modules with Wi-Fi function don’t support the 802.1X protocol. |
